Summary of Contents for BEKA HAMAX Kompakt M14
- Page 1 ...a product of BEKA BEKA-MAX Hydraulic pump HAMAX Kompakt Model M14 and M16 Original operating assembly manual Revision 0 -2019 © BEKA 201 All rights reserved!
-
Page 2: Table Of Contents
...a product of BEKA Contents Page General safety information Use in accordance with the regulations Scope of guarantee Safety instructions 4.1 Emphasizes 4.2 Qualification and training of the personnel 4.3 Danger due to non-observance of the safety information 4.4 Safety information for operators / operating staff 4.5 Safety information for maintenance, inspection and assembly work... -
Page 3: General Safety Information
· The mentioned technical data must not be exceeded in any case. · Retrofitting and repair works at the hydraulic pump may only be done by BEKA. All guarantees and warranties for damage of the hydraulic pump will expire, if improper lubricants have been used (e.g. -
Page 4: Safety Instructions
...a product of BEKA 4. Safety instructions · Read this operating- and assembly instructions before the assembly, start-up and operation. · Keep the instructions always on site. · Observe all warnings and safety instructions. Emphasises Please pay attention, not only to the safety instructions under this main point, but also to those special security advices which are inserted on the other pages.. -
Page 5: Safety Information For Operators / Operating Staff
Dispose process materials only in accordance with the safety data sheets of the lubricant manufacturer. Alterations and manufacture of spare parts without authority Rebuilding and modifications may only be done by BEKA. For components, retrofitted by the operator, BEKA does not assume guarantee nor claims for damages. Use only original spare parts. -
Page 6: Use Of Hydraulic Hose Lines
...a product of BEKA 5. Use of hydraulic hose lines If hydraulic hose lines are installed at the pump, the operator has to observe / ensure the following:. · Inspections regarding proper assembly and function have to be carried out according to the regionally applicable guidelines. -
Page 7: General Description
...a product of BEKA General description The hydraulically actuated grease pump BEKA HAMAX compact is mainly used to lubricate hydraulic hammers or other construction machinery attachments. Due to its compact design, it can be mounted directly at the attachment. As the drive is effected via a hydraulic motor (Pos. 9, fig. 1 and fig. 2), continuous supply of lubricant is ensured. The delivery rate can be varied with a throttle (pos. -
Page 8: Technical Data
...a product of BEKA 9. Technical data Hydraulic motor: Supply: Hydraulic hammer circuit, 870-4641 psi The following chisel pastes are permitted for the use with 60-320 bar Difference pressure in operation: min. 435 psi this grease pump. Additionally please also observe the... -
Page 9: Assembly Of The Pump
S2 (fig. ). Two hex. bolts M16x120 with lock washers are included in the scope of supply for fastening the pump. These must be tightened using a torque wrench (110 Nm). © BEKA 201 All rights reserved! -
Page 10: Installation Dimensions For Model M14
...a product of BEKA 11.3 Installation dimensions for model M14 Fig. 3: View "Z” Hydraulic supply socket Flange connection Hydraulic return socket, (Ø13,8) Flange connection Lubricant connector (Ø13,8) Ø8 Flange connection (Ø13,8) Ø13,8 Drilling pattern Hydraulic supply socket, Cartridge holder... -
Page 11: Operating Principle
12.1 Functional description The hydraulic pump BEKA HAMAX compact is connected to the hydraulic system of the carrier unit via the pressure pipe P (fig. ). The hydraulic oil is routed through a filter with cover (pos. 7, fig. 5), via the setting throttle (pos. 8, fig. 8) and to the hydro motor (pos. -
Page 12: Start Up
...a product of BEKA 13. Start up 13.1 Change of the cartridge At initial equipment, fill the lubricant line using the lubrication nipple at the front of the pump (see pos. 4, fig. 9). Before the first installation of a cartridge, slightly grease the O-rings in the adapter (pos. 2, fig. 10). -
Page 13: Ventilation Of The Lubrication System
Ventilate the whole lubrication system after the first operation and after each lubricant exchange! · Ventilation is done at pressure less operation and open outlets of the system. · Operate the pump until lubricant comes out of the pressure connection without air inclusions. © BEKA 201 All rights reserved! -
Page 14: Maintenance
...a product of BEKA 1 . Maintenance Stop the voltage feed, before starting with maintenance or repair Maintenance and repair work may only be done at standstill of the central lubrication pump and pressure less conditions. Check the surface temperature of the device, due to danger of burning by radiant heat. -
Page 15: Change Of The Pumping Element
(pos. 1, fig. 1 ). Slightly grease the O-ring on the closure screw (pos. 9, fig. 1 ) before assembly. When using copper paste, you must replace the pump element after approx. 0 service hours due to Caution! the solids content! © BEKA 201 All rights reserved! -
Page 16: Ordering Number
...a product of BEKA 16. Ordering number Pump design Cartridge type Mounting thread Cartridge Item no. Version J Type J without 10118527 Type S without 10118473 Version S Type S with / CU-GR-Paste 10118483 Type S with / EP-2 grease... -
Page 17: Troubleshooting
Oil comes out of the lateral Shaft sealing ring at hydro motor Exchange hydro motor relief hole defective 20. Spare part list and drawing Spare part lists and drawings are available on request. © BEKA 201 All rights reserved! -
Page 18: Declaration Of Incorporation
...a product of BEKA 21. Declaration of incorporation © BEKA 201 A 9 ll rights reserved! - Page 19 ...a product of BEKA © BEKA 201 All rights reserved!
- Page 20 ...a product of BEKA © BEKA 201 A 9 ll rights reserved!
- Page 21 ...a product of BEKA For your notice © BEKA 201 All rights reserved!
- Page 22 ...a product of BEKA For your notice © BEKA 201 A 9 ll rights reserved!
- Page 23 ...a product of BEKA For your notice © BEKA 201 All rights reserved!
- Page 24 ...a product of BEKA ...a product of BEKA BEKA BAIER + KÖPPEL GmbH + Co. KG Beethovenstraße 14 D-91257 PEGNITZ Tel. +49 9241 / 729-0 +49 9241 / 729-50 POSTFACH 1320 D-91253 PEGNITZ http://www.beka-lube.de E-Mail: beka@beka-lube.de beka@beka-max.de Other products from our range of supplies:...
