6.3.1 Disassembly of a pump element
A)
Disconnect the device from the power supply (pos. 1, see fig. 5) and secure it against recommissioning.
Fig. 5:
1
B)
Unscrew the pump element.
Fig. 6:
Make sure that the piston of the pump element does not remain in the pump housing!
Caution!
If the piston remains in the pump housing, the eccentric may be damaged or the device might block.
...a product of
AF 24
13
© BEKA 201
9 All rights reserved
!
