8. Starting at the top, press the shroud retainers into the rear shroud securing it to the tower frame.
9. Install screws and washers securing the bottom cap to the bottom of the tower frame using an 8mm Allen wrench.
Item
1
2
Item
1
2
3
Tighten hardware to 8-10 ft-lb (10.8-13.5 Nm).
Page 16 of 36
Description
Shroud Retainer
Rear Shroud
Description
Bottom Cap
Screw, M10 x 1.5, 20mm
Washer, Flat 3/8"
Qty.
6
1
Qty.
1
2
2
