2. Route cable through pulleys brackets on the main frame.
3. Install screw, washers, and locknut securing the pulley to the main frame using an 8mm Allen wrench and 17mm wrench.
Item
1
2
3
4
5
Tighten hardware to 20-25 ft-lb (27.1-33.9 Nm).
Page 21 of 36
Description
Pulley, 4.5" OD
Cable
Screw, M10 x 1.5, 50mm
Washer, Flat 3/8"
Nut, M10 x 1.5, Hex Nylock
Qty.
1
1
1
2
1
