CYBEX Ion Series Assembly Instructions Manual page 11

Components
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Hardware Kit
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Description
Main Frame
Seat Frame
Bottom Cross Brace
Front Cross Brace
Lower Pulley Assembly
Work Arm Assembly
Leg Curl Assembly
Leg Extension Assembly
Cam
Back Pad
Seat Pad
Roller Pad
Front Cap
Multilingual Label Sheet
Cable
Increment Weight Assembly
Head Plate Assembly
Weight Stack
(Weight Plates)
Description
Hardware Kit, CI-LCE
Nut, M10 x 1.5, Hex Nylock
Nut, M10, Hex Jam
Nut, M16, Hex Jam
Washer, Flat 3/8"
Screw, M5 x 10, Phillips
Screw, M6, HCS, 50mm
Screw, M10 x 1.5, 25mm, Flat Head
Screw, M10 x 1.5, 25mm
Screw, M10 x 1.5, 30mm
Screw, M10 x 1.5, 40mm, Low Head
Screw, M10 x 1.5, 70mm
Screw, M10 x 1.5, 100mm
Screw, M10 x 1.5, 110mm
Screw, M10 x 1.5, 120mm
Page 9 of 36
Qty.
1
1
1
1
1
1
1
1
1
1
1
4
1
1
1
1
1
1
(12)
Qty.
1
7
3
1
36
4
4
2
10
11
3
1
1
2
2
