2. Install screws securing the front cap to the tower frame using a 10 mm socket wrench and ratchet.
NOTE: Screw heads can be accessed from the top or bottom.
3. Press grommets into holes at the top of the tower frame.
4. Install screws securing the tube caps to the tower frame using a Phillips screwdriver.
5. Press top cap down into the holes at the top of the tower frame.
6. Select the appropriate language from the multilingual label sheet. Remove backing from multilingual label and apply to the left
and right slots in the front cap.
Item
1
2
Tighten hardware to 10-13 in-lb (1.1-1.5 Nm).
Item
1
2
3
4
Tighten hardware to 10-13 in-lb (1.1-1.5 Nm).
Item
1 Multilingual Label with General Warning
2
Page 24 of 36
Description
Front Cap
Screw, M6, HCS, 50 mm
Description
Top Cap
Tube Cap
Screw, 8 x ¾" Phillips
Grommet
Description
Front Cap
Qty.
1
4
Qty.
1
2
2
2
Qty.
1
1
