Technical Data - SPECTRO SPECTROCUBE C XEP06C Original Operating Instructions

3

Technical data

Description
Instrument height
Instrument width
Instrument depth
Instrument weight
Place of installation
Operating voltage range
Spectrometer power consumption (without
PC)
Standby mode (deactivated X-ray tube)
Fuse rating
Temperature range
Optimum temperature range
(within specifications)
Atmospheric humidity
Protection class / Contamination class
EMC environment
SPECTROCUBE C — 28.08.2019
Value
380 mm (15')
520 mm (20.5'')
540 mm (21.3'')
approx. 56 kg (~124 lbs)
Inside of dry, dust-free rooms up to an
altitude of 2000 m above sea level,
vibration-free (not subject to impact or
vibration load conditions)
90 to 253 V AC / 50 / 60 Hz
145 W
50 W
16 A (slow-blow)
+ +10° C to +35° C (50 to 95 °F)
+ +15° C to +30° C (59 to 86 °F)
10 to 80 % (non-condensing) at 25° C
(77° F)
10 to 75 % (non-condensing) at 30° C
(86° F)
IP 30 (DIN 40050)
Contamination class II
(laboratory environment)
Industrial environment / Laboratory
environment
Technical data
— 15
