LOCAL VISUAL POSITION INDICATOR

All J4C actuators are supplied with a local visual position indicator comprises a black base with a
yellow insert that shows, both the position and direction of rotation (Fig.6).
The open and close positions have the following logos molded into the top cover OPEN 90 and CLOSE 0.
Opening = Closing =
Fig. 6 0 = CLOSE Fig. 6 90 = OPEN
LOCAL VISUAL POSITION INDICATOR
THREE YELLOW INDICATORS:
TWO YELLOW INDICATORS:
For 3 way ball valve, T port.
For 3 way ball valve, L port.
