ACTUATOR OPERATIONAL STATUS

MODELS: 20, 35, 55, 85, 140 & 300
The LED Light provides visual communication between the actuator and the user.
The current operational status is shown by different LED colors.

ON-OFF ACTUATOR

Without power supply
.........................................................................................................................................................................................................................................................
In open position
...........................................................................................................................................................................................................................................................................
In close position
...........................................................................................................................................................................................................................................................................
Opening
...................................................................................................................................................................................................................................................................................................
Closing
......................................................................................................................................................................................................................................................................................................
Torque limiter function on, moving from close to open
Torque limiter function on, moving from open to close
Actuator in MANUAL mode (Exceeded time)
The actuator has stopped (no close/no open position)
In middle position
.....................................................................................................................................................................................................................................................................
