Functional Specifications

Print method
Print direction
Character density
Paper handling
Single Forms
Continuous forms
Paper type
Paper size
Continuous
Cut sheets
Paper thickness
Paper length
By software
By control panel
Number of copies
Command sets (emulations)
Impact dot matrix with a 0.23 mm (0.009 in), 24-wire head
Bidirectional logic-seeking
Horizontal X vertical
Letter (10 cpi): 36 X 24 dots
Letter (12 cpi): 30 X 24 dots
Draft: 12 X 24 dots
With the Paper Path Select Lever in the Single Sheet position,
single sheets or forms may be used. The printer automatically
senses that paper has been manually inserted. When paper is
detected, the printer will advance the form to the first print line.
With the Paper Path Lever set to the Continuous Form position,
continuous forms may be printed. Paper is loaded and
adjusted via keys. Forms may be advanced to tear off feature
by operator or by host. Continuous forms are parked while sin-
gle sheets are used.
1-to 4-part side-glued or paper-stapled fanfolded continuous
forms or single page top-glued forms.
Width: 102–216 mm (4–10.5 in)
Length: 102 mm (4 in) or greater
Width: 102–267 mm (4–10.5 in)
Length: 102 mm (4 in) or greater
Up to 0.35 mm (0.014 inch)
Programmable in one line or inch increments
3, 3.5, 4, 5.5, 6, 7, 8, 8.5, 11 (Letter), 11 2/3 (A4), 12, 14, or 15
inches (Default is 11 inches.)
1 to 126 lines
Up to 4, including the original
Epson-EP2
IBM Proprinter XL24E (2390+)
Intermec 6820
Printer and Paper Specifications
B-3
