Dascom Tally MIP480 User Manual page 51

INSTALL Options Values
32 KBYTE
64 KBYTE
<I/F TYPE>
AUTO
SERIAL
USB
WIRELESS
BLUETOOTH
<BAUD RATE>
4800 BPS
9600 BPS
19200 BPS
38400 BPS
<PARITY>
NONE
ODD
EVEN
<DATA BIT>
8 BIT
7 BIT
Description
32K bytes
64K bytes
NOTE: The larger the input buffer selected,
the smaller the download buffer becomes.
Even with 64K bytes of input buffer, a minimal
download buffer is provided. If you need a
larger capacity for downloading fonts, reduce
the input buffer.
Select the type of interface to the computer.
Both interfaces are ready for communication.
The printer communicates with the interface
from which it first receives data. The interface
is active until the input buffer becomes empty.
RS-232 Serial interface
USB interface
Wireless interface
Bluetooth interface
The baud rate is in bps (bits per second).
Select the same baud rate as that used by
your computer or modem.
4800 Bits Per Second
9600 Bits Per Second
19200 Bits Per Second
38400 Bits Per Second
Parity setting
Select the same word parity setting that is
used by your computer or modem.
None causes transmission in both directions
without parity bit
The bytes are checked to ensure they have
odd parity.
The bytes are checked to ensure they have
even parity.
Word Length setting
Select the same word length setting that is
used by your computer or modem.
8 Data bits per data byte
7 Data bits per data byte
Using Special Mode
4-17
