Paper Handling
Overview of Paper Operations
The following levers and keys are used in paper handling. Lift the cover to locate these
levers inside the printer.
•
Print Gap lever on the left side under the cover
•
Paper Select lever on the right side under the cover
The following figure shows the location of each lever, indicators, and keys:
Print Gap Lever
•
All keys on the control panel for primary and alternative functions are labeled below
and above respectively.
Control
Panel
2-8
Printer Controls and keys
Paper Select
Lever
Control
keys
Indicator
Lights
