USB Interface (Universal Serial Bus)

Features

Full compliance with the Universal Serial Bus Specification Revision 2.0.
USB Function Controller with two FIFO-based Endpoints:
•
One bidirectional Control Endpoint 0 (8 bytes)
•
One receive Endpoint 1 (1*64 byts)
The signaling bit rate is 12 Mb/s (Full speed).
USB (Universal Serial Bus) Interface Pin Assignment
Pin No. Signal
1 VBus
2 -Data(D-)
3 +Data(D+)
4 GND
Connecter type
Printer side Type B Receptacle
Cable side Type B Plug
Interface Information
D-5
