Table 2–12: Warranted characteristics — Triggering system
Name
Sensitivity, Edge-Type Trigger, Coupling
1
set to "DC"
Width, Minimum Pulse and Rearm, for
Pulse Triggering
The minimum pulse widths and rearm
2
widths and transition times required for
Pulse-Type triggering.
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Description
Trigger source Sensitivity
Any Channel TDS 694C: 0.35 division from DC to 50 MHz,
increasing to 1 division at 3 GHz main, 1.5 GHz delayed
TDS 680C & 684C: 0.35 division from DC to 50 MHz,
increasing to 1 division at 1 GHz
TDS 500D, 714L, 724D, & 754D: 0.35 division from DC to 50 MHz,
increasing to 1 division at 500 MHz
TDS 580D & 784D: 0.35 division from DC to 50 MHz, increasing to
1 division at 1 GHz
TDS 794D: 0.35 division from DC to 50 MHz,
increasing to 1 division at 1.5 GHz
TDS 600C: 250 mV from DC to 50 MHz,
Auxiliary
increasing to 500 mV at 100 MHz
TDS 500D, 714L, 724D, & 754D: 400 mV from DC to 50 MHz,
increasing to 750 mV at 100 MHz
TDS 580D & 784D: 250 mV from DC to 50 MHz,
increasing to 500 mV at 100 MHz
TDS 794D: 250 mV from DC to 50 MHz,
increasing to 500 mV at 100 MHz
For vertical settings > 10 mV/div. and ≤1 V/div at the BNC input
Minimum pulse
width
Pulse class
Glitch 1 ns
Runt 2 ns
TDS 694C: 1 ns
Time-Qualified 2 ns
Runt TDS 694C: 1 ns
Width 1 ns
Timeout 1 ns
2
Slew Rate 600 ps
Warranted Characteristics
Minimum re-arm width
2 ns + 5% of Glitch Width Setting
2 ns
TDS 694C & TDS 700D/714L: 8.5 ns + 5% of
Width Setting
2 ns + 5% of Width Upper Limit Setting
2 ns + 5% of Width Upper Limit Setting
TDS 694C & TDS 700D/714L: 8.5 ns + 5% of
Delta Time Setting
2–23
