Introduction
1.1 Feature Highlights
1.1

Feature Highlights

Ethernet Ports
Rated for Reliability in Harsh Environments
Power Supply
1.2

Description

The RUGGEDCOM RSG909R features various ports, controls and indicator LEDs on the
front panel for connecting, configuring and troubleshooting the device.
3
4
5
6
2
6 x 10/100/1000Base-TX copper Ethernet ports
3 x 1000Base-SX/LX SFP transceivers
Immunity to EMI and heavy electrical surges
Certified for use in explosive environments in accordance with the ATEX directive
Hazardous Location Certification: Class I Division 2
-40 to 85 °C (-40 to 185 °F) ambient operating temperature (no fans)
Die Cast Aluminum
DIN or panel mounting options provide secure mechanical reliability
[Optional] Conformal coated printed circuit boards
Fully integrated power supply
Dual HI AC inputs: 88-300 VDC or 85-264 VAC
Dual low-voltage DC inputs: 12, 24 or 48 VDC
Terminal blocks for reliable maintenance free connections
CSA/UL 62368-1 safety approved to 85 °C (185 °F)
1
2
7
8
9
RUGGEDCOM RSG909R
Installation Manual, 02/2021, C79000-G8976-1388-12
