Copper Ethernet Port Specifications

The following details the specifications for copper Ethernet ports that can be ordered
with the RUGGEDCOM RSG909R.
Speed
Connector
Duplex
Cable Type
Wiring Standard
Maximum Distance
Isolation
a
Auto-negotiating.
b
Shielded.
c
Auto-crossover and auto-polarity.
d
Typical distance. Dependent on the number of connectors and splices.
e
RMS 1 minute.
5.5

Operating Environment

The RUGGEDCOM RSG909R is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage Temperature
Ambient Relative Humidity
Maximum Altitude
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Operating temperature may vary based on the limitations of installed SFPs. Refer to the RUGGEDCOM
SFP Transceivers Catalog for SFP temperature ratings.
c
Non-condensing.
RUGGEDCOM RSG909R
Installation Manual, 02/2021, C79000-G8976-1388-12
10 Mbps
Ports

IEEE
IEC
IEC
a
10/100/1000Base-TX
RJ45
a
FDX/HDX
b
> CAT 5
c
TIA/EIA T568A/B
d
100 m (328 ft)
e
1.5 kV
ab
c
5.4 Copper Ethernet Port Specifications
100 Mbps
1000 Mbps Ports
Ports

-40 to 85 °C (-40 to 185 °F)
-40 to 85 °C (-40 to 185 °F)
5% to 95%
2000 m (6562 ft)
Technical Specifications
Notes
100Base-TX/100Base-FX
Precision Time Control
(PTP) Version 2
Media Redundancy
Protocol (MRP)
High-Availability Seamless
Redundancy (HSR), Parallel
Redundancy Protocol (PRP)
33
