LO Power Supply Configurations
Figure 2.15
2.7
Connecting the Device to the Network
Steps to connect the device to the network are application-specific.
RUGGEDCOM RSG909R
Installation Manual, 02/2021, C79000-G8976-1388-12
-
+
Single LO DC Power Input
Configuration
2.7 Connecting the Device to the Network
Figure 2.16
Dual LO DC Power Input
Configuration
Installing the Device
-
+
-
+
19
