Installing the Device

The following sections describe how to install the device, including mounting the
device, installing/removing modules, connecting power, and connecting the device
to the network.
Electrocution hazard – risk of serious personal injury and/or damage to
Before performing any maintenance tasks, make sure all power to the device has
been disconnected and wait approximately two minutes for any remaining energy
to dissipate.
Radiation hazard – risk of serious personal injury
This product contains a laser system and is classified as a Class I LASER PRODUCT.
Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
This product contains no user-serviceable parts. Attempted service by unauthorized
personnel shall render all warranties null and void.
Changes or modifications not expressly approved by Siemens AG could invalidate
specifications, test results, and agency approvals, and void the user's authority to
operate the equipment.
This product should be installed in a restricted access location where access can only
be gained by authorized personnel who have been informed of the restrictions and
any precautions that must be taken. Access must only be possible through the use
of a tool, lock and key, or other means of security, and controlled by the authority
responsible for the location.

General Procedure

The general procedure for installing the device is as follows:
The user is responsible for the operating environment of the device, including
maintaining the integrity of all protective conductor connections and checking
Installation Manual, 02/2021, C79000-G8976-1388-12
