Technical Specifications

This section provides important technical specifications related to the device.
5.1

Power Supply Specifications

Note
When determining cable lengths, make sure the minimum input voltage for the
power supply is provided at the power source.
Hazardous Environments
Power
Supply Type
Minimum
LO
11.1 VDC
HI
100 VDC
100 VAC
a
Current consumption may vary based on configuration.
Non-Hazardous Environments
Power
Supply Type
Minimum
LO
10 VDC
HI
88 VDC
85 VAC
a
Current consumption may vary based on configuration.
RUGGEDCOM RSG909R
Installation Manual, 02/2021, C79000-G8976-1388-12
Input Voltage
Maximum
Nominal
55 VDC
12 VDC, 24
VDC, 48 VDC
270 VDC
125 VDC,
250 VDC
240 VAC
110 VAC,
220 VAC
Input Voltage
Maximum
Nominal
60 VDC
12 VDC, 24
VDC, 48 VDC
300 VDC
125 VDC,
250 VDC
264 VAC
110 VAC,
220 VAC
Internal
Isolation
Fuse Rating
5 A
1.5 kVDC
3.15 A
5 kVDC
3.15 A
5 kVDC
Internal
Isolation
Fuse Rating
5 A
1.5 kVDC
3.15 A
5 kVDC
3.15 A
5 kVDC
5
Maximum
Power
a
Consumption
13.4 W
15.3 W
15.5 W
Maximum
Power
a
Consumption
13.4 W
15.3 W
15.5 W
31
