Freeze-dryer Beta 1-8 LSCbasic
Freeze-dryer Beta 2-8 LSCbasic
6 Operation
1
Not available for Alpha 3-4 LSCbasic
48 / 107
Option: USB process recording
(see chapter 6.6 - "Optional extensions")
•
Select the "USB process recording" function in the dialogue box "Tools".
•
Select the input fields ("Batch data"). A keyboard for the data input will
be displayed.
•
If necessary, select the "Options" tab, choose between manual or
automatic recording, and define a recording interval.
•
Press the "return" button in order to close the dialogue box.
The process recording will now run in the background.
Fig. 23: Dialogue box "USB process recording"
1
Option: Lifting hoist
(see chapter 6.6 - "Optional extensions")
This function is described in the separate operating manual of the lifting
hoist.
Button "Set" (5)
This button is used to enter the set values for the individual phases of the
freeze-drying process prior to the start of the process. Value ranges have
been saved for the various phases. These value ranges can be displayed in
the input window with the aid of the buttons "min" or "max" (see chapter
6.5.2.1 - "Entering set values").
Dialogue box "Process and equipment messages" (6)
This dialogue box is used to view and save all of the error messages and
other messages. In the event of an error or message, the window "Process
and equipment messages" will open automatically. In addition, a sound
signal is emitted until the error is acknowledged.
