Chapter 1 General Information

1.1 Introduction

The IPC-610F is a PC/AT-compatible computer designed for industrial applications. This rugged,
all-steel chassis meets the EIA RS-310C 19" rackmount standard. The unit includes a 14-slot PC-bus
compatible passive backplane, and a more efficient switching power supply in a single fan-cooled
chassis.
The passive backplane configuration of the IPC-610F minimizes downtime, simplifies troubleshooting,
makes upgrading easier and allows for a more efficient system package. All electronic components are
modular in design and can be easily serviced. The IPC-610F accommodates most plug-in cards,
including CPU, video, disk controller, and I/O interface cards. They can be conveniently installed and
replaced from the top of the unit.
The IPC-610F will withstand shock, vibration, dust, and a wide range of operating temperatures in
harsh industrial environments. The chassis is positively pressurized by two filtered push-pull cooling
fans to exclude dust and dirt. A lockable door protects drives and switches from tampering and foreign
particles.

1.2 Model List

Model Number
IPC-610BP-30XF
IPC-610MB-30XF

1.3 Specifications

General
• Construction: Heavy-duty steel
• Disk drive capacity: Three half-height 5¼" drives and one 3½" drive accessible from the front
panel; and one 3½" HDD inside the chassis
• Cooling system: One 32 CFM cooling fan (flow-out) on the rear panel for the power supply, another
86 CFM fan (flow-in) with Hot-plug connector on the front panel with an air filter
• Keyboard connector: Pre-wired DIN connectors on rear panels
• Controls: Reset, power on/off and keyboard-lock switches
• Indicators: LEDs for power on/off, HDD and keyboard-lock
• Speaker: One 5 Ω, ½ watt speaker
• Weight: 18.5 kg (40.7 lb)
• Paint color: Pantone 414U
• Dimensions (W x D x H): 482 x 452 x 177 mm (19" x 17.8" x 7") for IPC-610BP-30XF,
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Version
Blackplane
Motherboard
482 x 502 x 177 mm (19" x 19.8" x 7") for IPC-610MB-30XF
Power Supply
PS-300ATX 482 x 452 x 177 mm
PS-300ATX 482 x 502 x 177 mm
IPC-610F User's Manual
Dimensions
(W x D x H)
1
