Access Lists

IPX Routing

To display the contents of the DNS Server table, use the command:


list dns servers
To delete a domain entry, use the command:


delete dns server <domain name>
Access lists enable you to restrict which Remote Subnets are allowed to access the
Management services of the OCR812.
To add a remote subnet to the access list, use the following command:


add access <ip subnet address>
To remove a subnet from the access list:


del access <ip subnet address>
To display the access list:


list access
In addition to adding subnets to the list, you can enable access to all hosts on the
local LAN.
To enable LAN access:


enable lan access
To enable the Access List functionality:


enable access_list
To disable the Access List functionality:


disable access_list
To show the status of the Access List functionality:


show access
The OCR 812 can be configured as an IPX router to forward IPX packets between
the local LAN interface and one or more remote sites. A forwarding table is
maintained which specifies which interface to route an IPX packet based on the
destination IPX network number. Entries into the forwarding table are both static
and dynamic. Static entries are based on the LAN's network number, the remote
site WAN interface number, and user configured static routes. Dynamic entries are
added when RIP is enabled and routes are learned from neighboring routers.
To configure IPX routing, IPX must be defined on both the LAN interface and one
or more remote sites. On the LAN, an IPX network must exist with a specified IPX
network number. On the remote sites, IPX forwarding needs to be enabled, and
the WAN interface address need to be configured. The WAN interface can be
Unnumbered (set to 0), Numbered, or dynamically learned if PPP is used.
IPX Routing 6-31
