Set Facility <Facility_Name> Loglevel [Level]; Set Ilmi Vpi <Number> Vci <Number; Set Interface <Interface_Name; Set Ip Network <Name - 3Com OfficeConnect Remote 812 Cli User's Manual

set facility
<facility_name>
loglevel [level]
set ilmi vpi <number>
vci <number>
set interface
<interface_name>
set ip network <name>
timeout Number of seconds to wait before deciding a request to a Name Server has
timed out. Minimum interval and default is 5 seconds, maximum interval is
120 seconds.
Sets the severity reporting level for a facility. The hosts that will receive the error
log entries are defined using add syslog loglevel. Use list facilities to see what the
current loglevel is for each facility. The levels:
CRITICAL - a serious system error, which may effect system integrity


UNUSUAL - an abnormal event, which the system should recover from


COMMON - a regularly occurring event that is not frequent


VERBOSE - a regular periodic event, e.g. a routing update message


DEBUG - for debugging purposes only


This allows modification of the Virtual Path or Channel ID that will be used for
exchanging ILMI (Integrated Local Management Interface) messages.
Parameter Description
vpi The virtual path identifier for the ILMI.
vci The virtual channel identifier for the ILMI.
filter_access [ON | OFF]


input_filter <filter_name>


output_filter <filter_name>


Sets filter parameters for the specified protocol on the specified interface. You can
see the available filter files using list filters, view the contents of a filter file using
show filter, and add filter files to FLASH memory using TFTP.
Parameter Description
<interface_name> Designation of interface you are setting parameters for. Limit of 32
characters.
filter_access ON causes filters specified for an interface with a set interface command,
to override filters specified with a set user command, when the filters are
of the same type.
input_filter Name of filter file you wish to be applied to the input stream coming in on
the specified interface. Limit: 20 characters.
output_filter Name of the filter file you wish to be applied to the output stream leaving
the specified interface. Limit: 20 characters.
broadcast_algorithm [number]


reassembly_maximum_size [number]


rip_authentication [string]


rip_policies_update <rip_policies>


routing_protocol [NONE | RIPV1 | RIPV2]


CLI Commands B-27
