Operating Information

General Features

TPS2000 Series Digital Storage Oscilloscopes Service Manual
TPS2000 Series oscilloscopes are two- or four-channel instruments in small,
lightweight, bench-top chassis.
In addition to a list of general features, this chapter covers:
H How to perform a brief functional check
H How to use the self-calibration routine
H How to restore factory default settings
For more detailed operating information, refer to your user manual.
The next table and list describe the general features.
Table 2- - 1: Oscilloscope General features
Model Channels
TPS2012 2
TPS2014 4
TPS2024 4
H Battery powered or line powered
H Two rechargeable battery packs (second battery pack optional)
H Independently isolated channels with no shared common ground
H Floating measurements
H TPS2PWR1 Power Analysis Application software (optional)
H Support for compatible voltage probes and current probes
H Context-sensitive help system
H Color LCD display
H Selectable 20 MHz bandwidth limit
H 2500 point record length for each channel
H Autoset
Bandwidth Sample rate
100 MHz 1.0 GS/s
100 MHz 1.0 GS/s
200 MHz 2.0 GS/s
2- - 1
