Maintenance
F
From Figure 6--10
Figure 6- - 12: Oscilloscope troubleshooting tree (4 of 4)
6- - 24
No
Memory function
problem?
Yes
Verify memory
function with CF
card
Yes
Memory function
OK?
No
Replace
Compact Flash
board
Yes
Memory function
OK?
No
Replace
Acquisition
board
TPS2000 Series Digital Storage Oscilloscopes Service Manual
No
Communication
problem?
Yes
Replace
Acquisition
board
Instrument no
problem
Problem fixed
Battery charging
problem
Exchange IO
board
