Table 1- 1: Oscilloscope general characteristics (Cont.)
Measurements
Cursors Types
Automatic Measurements
Probe Compensator Output
Output Voltage, typical
Frequency, typical
Adjustment Interval
The recommended factory calibration interval is one year.

Table 1- 2: Oscilloscope display characteristics

Type
Resolution
Brightness
Contrast
1
Backlight Intensity , typical
1
Available through the display menu.

Table 1- 3: Oscilloscope physical characteristics

Size
Weight, approximate g , pp

Table 1- 4: Power source characteristics

Source Voltage of the AC Adapter
Power Consumption
TPS2000 Series Digital Storage Oscilloscopes Service Manual
Amplitude difference between cursors (∆V, ∆A, ∆VA)
Time difference between cursors (∆t)
Reciprocal of ∆t in Hertz (1/∆t)
Frequency, Period, Mean, Pk-Pk, Cycle RMS, Min, Max, Rise Time, Fall Time, Pos Width,
Neg Width
5 V ±10% into ≥1 MΩ load
1 kHz
145 mm (5.7 in) diagonal liquid crystal
320 x 240 vertical pixels
Adjustable
Adjustable, temperature compensated
2
60 to 100 cd/m
Height
Width
Depth
Instrument only
1 battery installed
2 batteries installed
160.8 mm (6.33 in)
336.3 mm (13.24 in)
129.5 mm (5.10 in)
2.7 kg (6.0 lbs)
3.2 kg (7.0 lbs)
3.7 kg (8.0 lbs)
90 to 264 VAC from 45 Hz through 66 Hz
rms
Instrument only: 30 watts max.
AC input to AC adapter: 36 watts.
Specifications
1- 7
