Table 1- 9: P2220 Probe specifications

Electrical characteristics
Bandwidth
Attenuation Ratio
Compensation Range
Input Resistance
Input Capacitance
Rise Time, typical
1
Maximum Input Voltage
Between Tip (Signal) and
Reference Lead
1
Maximum Input Voltage
Between Tip (Signal) and
Earth Ground
Maximum Voltage Between
Reference Lead and Earth
Ground
1
As defined in IEC61010-1: 2001. See certifications and compliances in Table 3.
The float voltage must be subtracted from the tip-to-earth ground voltage. For example, if the reference lead is floated to
2
30 V , the tip voltage to the reference lead is limited to 270 V
rms

Table 1- 10: P2220 Probe certifications and compliances

TPS2000 Series Digital Storage Oscilloscopes Service Manual
10X position
DC to 200 MHz
10:1 ±2%
15 pF to 25 pF
10 MΩ ±3% at DC
13.0 pF to 17.0 pF
< 2.2 ns
10X position 300 V
150 V
420 V peak, <50% DF, <1 s PW
670 V peak, <20% DF, <1 s PW
1X position 150 V
100 V
210 V peak, <50% DF, <1 s PW
330 V peak, <20% DF, <1 s PW
300 V ; derate at 20 dB/decade above 900 kHz to 13 V peak AC at 3 MHz and above. For
rms
nonsinusoidal waveforms, peak value must be less than 450 V.
Excursion above 300 V should be less than 100 ms duration. RMS signal level, including any DC
component removed through AC coupling, must be limited to 300 V. If these values are exceeded,
damage to the instrument may result. Refer to the Overvoltage Category on the next page.
10X position 300 V
150 V
420 V peak, <50% DF, <1 s PW
670 V peak, <20% DF, <1 s PW
1X position 150 V
100 V
210 V peak, <50% DF, <1 s PW
330 V peak, <20% DF, <1 s PW
2
30 V
rms
1X position
DC to 6 MHz
1:1 ±2%
Compensation is fixed; correct for all oscillo-
scopes with 1 MΩ input.
1 MΩ ±3% at DC
80 pF to 110 pF
< 50.0 ns
CAT II or 300 V DC CAT II
rms
CAT III or 150 V DC CAT III
rms
CAT II or 150 V DC CAT II
rms
CAT III or 100 V DC CAT III
rms
CAT II or 300 V DC CAT II
rms
CAT III or 150 V DC CAT III
rms
CAT II or 150 V DC CAT II
rms
CAT III or 100 V DC CAT III
rms
.
rms
Specifications
1- 11
