Adjustment Procedures

Required Equipment

TPS2000 Series Digital Storage Oscilloscopes Service Manual
This section contains an adjustment procedures for the TPS2000 Series
oscilloscopes.
Only qualified personnel should perform service procedures. Read the Service
Safety Summary and the General Safety Summary at the beginning of this manual
before performing any service procedures.
NOTE. The voltage references inside TPS2000 Series oscilloscopes are very
stable over time and should not require routine updates. Before performing any
procedure in this chapter, first verify that the oscilloscope does not meet
specifications. Refer to the chapter Performance Verification to verify the
specifications.
The equipment described in Table 5- -1, or a suitable equivalent, is required to
complete the procedure.

Table 5- 1: Required equipment

Description Minimum requirements
- - 20 V to 20 V, ±0.1%
DC Voltage Source
accuracy
60 kHz and 200 MHz, ±0.6%
Leveled Sine Wave
Generator amplitude accuracy
50 Ω BNC Cable
BNC male to BNC male,
≈ 1 m (36 in) long
50 Ω BNC Cable (two)
BNC male to BNC male,
≈ 25 cm (10 in) long
50 Ω Feedthrough
BNC male and female
Termination connectors
Dual Banana to BNC Banana plugs to BNC female
Adapter
BNC T One male and two female
BNC connectors
Examples
Wavetek 9100 Universal Calibration
System with Oscilloscope
Calibration Module (Option 250)
Fluke 5500A Multi-product Fl k 5500A M lti d t
Calibrator with Oscilloscope
Calibration Option
(Option 5500A-SC)
Tektronix part number 012-0482-00
Tektronix part number 012-0208-00
Tektronix part number 011-0049-01
Tektronix part number 103-0090-00
Tektronix part number 103-0030-00
5- 1
