4 Do not overcharge batteries!
5 Do not mix old and new batteries or batteries of
different types or manufacturers! Replace an entire
set of batteries at the same time.
6 Immediately remove used batteries from the device
and dispose of them properly!
7 Do not allow batteries to heat up!
8 Do not weld or solder directly on batteries!
9 Do not dismantle batteries!
10 Do not allow batteries to deform!
11 Do not throw batteries into fire!
12 Keep batteries out of the reach of children.
13 Do not allow children to replace batteries without
supervision!
14 Do not keep batteries near fire, ovens or other
sources of heat. Do not use batteries in direct
sunlight or store them in vehicles in hot weather.
15 Keep unused batteries in the original packaging
and keep them away from metal objects. Do not
mix unpacked batteries or toss them together! This
can lead to a short-circuit of the battery and thus
damage, burns or even the risk of fire.
16 Remove batteries from the equipment when it will
not be used for an extended period of time, unless
it is for emergencies!
17 NEVER handle batteries that have leaked without
appropriate protection. If the leaked fluid comes
into contact with your skin, the skin in this area
should be rinsed off under running water imme-
diately. Always prevent the fluid from coming into
contact with the eyes and mouth. In the event of
contact, please seek immediate medical attention.
18 Clean the battery contacts and corresponding con-
tacts in the device prior to inserting the batteries:

6. Technical data

AC motor
Power
Operating mode
Idle speed n
0
Carbide saw blade
Number of teeth
Swivel range
Mitre cut
Saw width at 90°
Saw width at 45°
Saw width at 2 x 45°
(double mitre cut)
Protection class
Weight
Laser class
Wavelength of laser
Laser output
Laser module power
supply
24 GB
230 - 240 V~ 50Hz
2150 Watt
S6 20% 5 Min*
3200 / 4500 min
-1
ø 255 x ø 30 x 2,8 mm
48
-45° / 0°/ +45°
0° bis 45° to the left
305 x 90 mm
215 x 90 mm
215 x 47 mm
II
15,5 kg
2
650 nm
≤ 1 mW
3 x LR44
button cell
* S6, continuous operation periodic duty.
Identical duty cycles with a period at load followed
by a period at no load. Running time 5 minutes;
duty cycle is 20% of the running time.
The work piece must have a minimum height of
3mm and a minimum width of 10 mm.
Make sure that the workpiece is always secured
with the clamping device.
Noise and vibration
Total vibration values determined in accordance with
EN
Sound pressure level L
pA
Uncertainty K
pA
Sound power level L
WA
Uncertainty K
WA
Wear hearing protection.
The effects of noise can cause a loss of hearing. Total
vibration values (vector sum - three directions) deter-
mined in accordance with EN 61029.
Residual risks
The machine has been built according to the state
of the art and the recognised technical safety re-
quirements. However, individual residual risks can
arise during operation.
• Health hazard due to electrical power, with the use of
improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the „safety instruc-
tions" and the „Proper use" are observed along with
the whole of the operating instructions.
• Do not load the machine unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the machine
in the processing and in cut precision.
• When cutting plastic material, please always use
clamps: the parts which should be cut must always
be fixed between the clamps.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual.
In doing so, your mitre saw provides optimal perfor-
mance.
• Hands may never enter the processing zone when the
machine is in operation. Release the handle button
and switch off the machine prior to any operations.
7. Before starting the equipment
• The equipment must be set up where it can stand
securely, i.e. it should be bolted to a workbench, a
universal base frame or similar.
61029.
95.23 dB(A)
3 dB
108.23 dB(A)
