Attention: Danger of accidents!
The wood must always rest on both sides of the saw blade in the prism of the swivel frame. (see arrows)
Attention: Danger of acci-
dents!
Wear safety shoes.
Attention: Danger of acci-
dents!
Read the operating manual
before commissioning!

6. Operator training

• Pass the safety instructions on to all persons who
work on the machine.
• The operating personnel must be at least 18 years
of age. Trainees must be at least 16 years of age
and may only work on the machine under supervi-
sion.
• Personnel working on the machine must not be dis-
tracted.
• Keep children away from the mains-connected ma-
chine.
• Wear close-fitting clothing. Remove jewellery, rings
and watches.
• Ensure that all of the safety information and danger
notices on the machine are in legible condition.
• Caution when working: Danger of injury for fingers
and hands due to the rotating cutting tool.
• Regular breaks must be taken during operation.
• Safety shoes and protective clothing must be worn
during operation.

7. Technical data

Item number
Dimensions
Overall length
Overall width
Overall height
Swivel frame support
Saw blades
Saw blade nut tightening torque
Saw blade idle speed
Saw blade cutting speed
Weight
26 | GB
HS720 / HS720 VL
5905109901/
39051109954
mm
mm
mm
mm
mm
Nm
1/min 1380
m/s 52
kg 95
www.scheppach.com
Attention: Danger of accidents!
Wear hearing protection.
Wear safety goggles.
Attention!
Tool continues to run after power discon-
nected!
Disconnect the device from the power supply
before carrying out any maintenance, clean-
ing or repair work!
For machines equipped with a combustion
engine, close the fuel valve!
HS720
39051109953
1270
730
1130
670
Ø 700 x 30 x 4.5 x 3.5 Z42 (HW)
Ø 700 x 30 x 4.2 x 3.2 Z84 (HW)
90
1400
52
89.5
HS720B
39051099953
1500
55
114
