7
FOR YOUR REFERENCE
Specifications (Continued)

D Transmitter

• Rated output power:
• Modulation:
• Frequency error:
• Spurious emissions:
• Adjacent channel power:
• FSK Error:
• FM Hum and Noise:

D Receiver

• Sensitivity:
• Adjacent channel selectivity:
• Intermodulation:
• Hum and Noise:
D Bluetooth
• Version:
• Output power:
• Profile:
• Modulation:
5 W (High), 2 W (Low 2), 1 W (Low 1)
Frequency modulation, FSK modulation
±1�0 ppm
USA/EXP version 70 dB minimum� 90 dB typical
EUR/AUS version 0�25 uW (Less than 1GHz),
1�0 uW (More than 1GHz)
IP730D 60 dB minimum 70 dB typical
IP740D 60 dB minimum 64 dB typical
5 % maximum, 1 % typical
34 dB minimum, 60 dB typical (Without CCITT Filter)
IP730D
USA/EXP version 0�32 uV maximum (at 12 dB SINAD)
0�22 uV typical (at 12 dB SINAD)
EUR/AUS version 0�0 dBuVemf maximum (at 20 dB SINAD)
–2�0 dBuVemf typical (at 20 dB SINAD)
IP740D
USA/EXP version 0�32 uV maximum (at 12 dB SINAD)
0�17 uV typical (at 12 dB SINAD)
EUR/AUS version 0�0 dBuVemf maximum (at 20 dB SINAD)
–2�0 dBuVemf typical (at 20 dB SINAD)
60 dB minimum, 67 dB typical
IP730D
USA/EXP version 70 dB minimum, 74 dB typical
EUR/AUS version 65 dB minimum, 67 dB typical
IP740D
USA/EXP version 70 dB minimum, 72 dB typical
EUR/AUS version 65 dB minimum, 66 dB typical
34 dB minimum, 60 dB typical
(Without CCITT Filter)
4�2
Class 2
HFP, HSP
GFSK, /4-DQPSK, 8DPSK
π
7-3
