D Transmitter; D Receiver - Icom ID-52E PLUS Basic Manual

9
SPECIFICATIONS

D Transmitter

• Modulation system:
FM/FM-N
DV
• Output power (at 7.4 V DC): High: 5.0 W, Mid: 2.5 W, Low2: 1.0 W, Low1: 0.5 W, S-Low: 0.1 W
• SAR 10g:
• Maximum frequency deviation:
FM
FM-N
• Spurious emissions:
• Microphone impedance:

D Receiver

• Receive system:
• Intermediate frequencies:
A band
B band
• Sensitivity:
Ham band
Outside Ham band
Band
BC band
A band
B band
* "WFM" is for only BC band. "FM" and "FM-N" is for only A/B band.
1
* "AM-N" is for only 108.000 MHz ~ 143.995 MHz.
2
• Audio output power:
Internal speaker
External speaker
• Selectivity:
FM
FM-N/DV
35
Variable reactance frequency modulation
GMSK reactance frequency modulation
5.49 W/kg
±5.0 kHz or less
±2.5 kHz or less
–60 dBc or less at High/Mid
–13 dBm or less at Low2/Low1/S-Low
2.2 kΩ
Double Conversion Superheterodyne
1st IF 58.05 MHz, 2nd IF 450 kHz
1st IF 57.15 MHz, 2nd IF 450 kHz
FM/FM-N 0.18 μV or less (at 12 dB SINAD)
DV 0.2 μV or less (at 1% BER)
Frequency range
(MHz)
76.000 ~ 108.000
108.000 ~ 136.991
137.000 ~ 142.000
142.005 ~ 148.000
148.005 ~ 174.000
225.000 ~ 259.995
260.000 ~ 354.995
355.000 ~ 374.995
375.000 ~ 399.995
400.000 ~ 479.000
137.000 ~ 148.000
148.005 ~ 174.000
375.000 ~ 399.995
400.000 ~ 479.000
0.75 W or more at 10% distortion into an 8 Ω load
0.2 W or more at 10% distortion into an 8 Ω load
55 dB or more
50 dB or more
FM/FM-N/WFM*
1
(12 dB SINAD)
or less
1 μV
–
or less
0.18 μV
0.18 μV or less
0.32 μV or less
0.56 μV or less
0.32 μV or less
0.5 μV or less
0.5 μV or less
0.32 μV or less
0.18 μV or less
0.32 μV or less
0.5 μV or less
0.32 μV or less
AM/AM-N*
2
(10dB S/N)
–
1 μV or less
1 μV or less
–
–
1.8 μV or less
1 μV or less
1.8 μV or less
–
–
–
–
–
–
