Control Signal Wiring Example: LECSC
Forced stop
Proximity dog
Forward rotation stroke end
Reverse rotation stroke end
Note 1) For preventing electric shock, be sure to connect the driver
Note 2) For interface use, supply 24 VDC ±10% 150 mA using an external source.
Note 3) The failure (ALM) is ON during normal conditions. When it is OFF (alarm occurs), stop the sequencer signal using the sequence program.
Note 2)
24 VDC
+
Power
CN6
−
supply
DICOM
DOCOM
EMG
DOG
LSP
LSN
10 m or less
,
s protective earth (PE) terminal (marked
AC Servo Motor Driver
LECSC
CN6
14 RD RA1
5
15 ALM RA2
17
16 ZP RA3
1
2
10 m or less
3
4 13 LZ
26 LZR
11 LA
24 LAR
12 LB
25 LBR
23 LG
Plate SD
Note 1)
PE
CN1
CC-Link
LECS 
Series
Ready
Failure
Note 3)
Return to origin completion
Z-phase pulse encoder
(Differential line driver)
A-phase pulse encoder
(Differential line driver)
B-phase pulse encoder
(Differential line driver)
Control common
,
) to the control panel s protective earth (PE).
