LECS 
Series
Control Signal Wiring Example: LECSB
This wiring example shows connection with a positioning unit (QD75D) manufactured by Mitsubishi Electric as when used in position
control mode. Refer to the LECSB operation manual and any technical literature or operation manuals for your PLC and positioning unit
before connecting to another PLC or positioning unit.
Positioning unit
QD75D (Manufactured by
Mitsubishi Electric)
CLEARCOM
CLEAR
RDYCOM
READY
PULSE F+
PULSE F–
PULSE R+
PULSE R–
PG0 COM
Emergency stop
Servo ON
Reset
Proportion control
External torque limit selection
Forward rotation stroke end
Reverse rotation stroke end
Upper limit setting
Analog torque limit
+10 V/Maximum torque
Note 1) For preventing electric shock, be sure to connect the driver
Note 2) For interface use, supply 24 VDC ±10% 300 mA using an external source.
Note 3) The failure (ALM) is ON during normal conditions. When it is OFF (alarm occurs), stop the sequencer signal using the sequence program.
Note 4) The same name signals are connected inside the driver.
Note 5) For command pulse input with a differential line driver method. For open collector method, it is 2 m or less.
53
24 VDC
Note 2)
14
13
12
11
15
16
17
S/S
18
PG0
9
10
10 m or less
Note 5)
10 m or less
2 m or less
LECSB
Note 4)
CN1
Note 4)
21
DICOM
CN1
DICOM
20
48
ALM
DOCOM
46
23
ZSP
CR
41
25
TLC
RD
49
24
INP
PP
10
PG
11
NP
35
NG
36
4
LA
LZ
8
5
LAR
LZR
9
6
LB
LG
3
7
LBR
SD
Plate
34
LG
33
OP
1
P15R
Plate
SD
Note 4)
CN1
EMG
42
SON
15
Note 4)
RES
19
CN6
3
MO1
PC
17
1
LG
TL
18
2
MO2
LSP
43
LSN
44
DOCOM
47
P15R
1
TLA
27
LG
28
SD
Plate
Note 1)
PE
,
s protective earth (PE) terminal (marked
Failure
RA1
Zero speed detection
RA2
Torque limiting
RA3
Positioning completion
RA4
10 m or less
A-phase pulse encoder
(Differential line driver)
B-phase pulse encoder
(Differential line driver)
Control common
Control common
Z-phase pulse encoder
(Open collector)
2 m or less
±10 VDC
±10 VDC
2 m or less
,
) to the control panel
s protective earth (PE).
Note 3)
Analog monitor 1
Analog monitor 2
