LEJ
Series
Work Load–Acceleration/Deceleration Graph (Guide)
LEJB40/Belt Drive: Horizontal
20000
The value of 50% or less is the same as duty ratio 50%
15000
Duty ratio: 50%
10000
5000
0
0 5
17
Duty ratio: 75%
Duty ratio: 100%
10 15
Work load [kg]
LEJB63/Belt Drive: Horizontal
20000
15000
10000
5000
0
20
0
The value of 50% or less is the same as duty ratio 50%
Duty ratio: 50%
Duty ratio: 75%
Duty ratio: 100%
5 10 15 20
Work load [kg]
25 30
