7.2

Parts List - Multi Gym

No. Name
1 connection tube
2 upright frame left
3 upright frame right
4 bending tube left
5 bending tube right
6 upper connection tube
7 upper bending tube right
8 upper bending tube left
9 hexagon bolt
10 lock nut
11 washer
12 chin up bar
13 upper plate
14 pulley frame tube right
15 pulley frame tube left
16 upright tube
17 tube with hole right
18 tube with hole left
19 lower plate
20 sliding tube right
21 sliding tube left
22 foot tube cover
23 end tube
24 hexagon bolt
25 lower base
26 upper base
27 guide rod
28 lock sleeve
29 sliding sleeve
30 rubber pad with groove
31 safety hook right
32 safety hook left
Specification
M10*75
M10
Φ10
M10*80
Φ25*1850
Φ60*Φ26*45
Qty.
1
1
1
1
1
1
1
1
54
100
210
1
4
1
1
2
1
1
4
1
1
2
2
14
2
2
2
2
2
2
1
1
53
