(Figure 6.4) Close up of the Series1 V-wheel carriage assembly and spindle block.
Engraving
Motor Belt
Spindle
Assembly
Spindle Block
Z-Lead Screw
(Figure 6.5) Series1 version T-Slot Table Model with V-wheel carriage design
Shown below is the Vision 1624 (Series1 Vision 1212 and 1224 were similar).
Carriage Assembly
Engraving Motor
Material
Guides
T-Slot Table
Quick Lock Vise
Engraving Motor
Z-Axis Knurled
Thumb Wheel
X-Axis Rail
V-Wheel
Stepper Motors
Y-Axis
Lead Screw
Chapter 6
Motor Speed
Controller Plug
Gantry
(the X-Axis
Lead Screw
is under the
metal cover)
Base Plate
Page 27
