Spindle Assembly Description
Our most recent tables (the "Series 3's") include our newest spindle design, which now
incorporates tension spring adjustment.
(Figure 4.1) The Series 3 Top-
Loading Spindle Assembly
10.
8.
1. Pulley
2. Inner Spindle Housing (under sleeve)
3. Outer Spindle Sleeve
4. Pressure Spring Adjuster
5. Pressure Spring
6. Micrometer
7. Retainer Ring
8. Nose cone
(Figure 4.2) The Series 3 Top and
Bottom-Loading Collet Spindle
Assembly
14.
1.
2.
9.
3.
4.
5.
12.
13.
11.
6.
7.
15.
9. Draw Bar
10. Cutter
11. Solid Collet (Optional)
12. Split Collet
13. Pointer
14. Cutter Knob
15. Cutter Knob Setscrew
