7. Twist the ISU right cover (a) and
release two hooks (b) in the direction of
the arrow.
8. Release the protrusion (c) of ISU right
cover (a) in the direction of the arrow
and detach it.
9. After twisting the DIMM cover(a),
remove it while sliding it
2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA
c
2
b
Figure 4-118
1
2
a
Figure 4-119
4-65
1
a
