Teldat S.A.
Message
Message
A.4 Technical Specifications
Hardware Architecture
PROCESSORS
MEMORY
STORAGE UNIT
Wireless WAN Interface
STANDARDS
SPEED
CONNECTOR
ANTENNA
Serial COM Interface
LOCAL TERMINAL
CONNECTOR
Power Supply
INPUT VOLTAGE
INPUT CURRENT
MAXIMUM POWER
Dimensions and Weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
REGESTA 1
The device's coverage is above the minimum threshold
If the parameters don't follow a pattern: DEVICE $1 REGISTERED
AT91SAM9260 (ARM9)
64 Mbytes in SDRAM
FLASH Memory (4/16Mbytes)
GSM, GPRS
GSM Circuit switched dada (CSD) transmission:
Asynchronous transparent CSD up to 14400 bps
Asynchronous non-transparent CSD up to 9600 bps
V.110
GPRS:
GPRS class 10,
Mobile station class B
Coding scheme 1 to 4
PBCCH support
RF SMA Female
Please see the antennas catalog for Cellular interfaces.
RS232 V.24 9.600-8-PAR-1- without flow control.
DB9 female, on the front panel of the device.
220 V CA ±10 %, 50/60 Hz
0,03 A@220Vac
6 W
Ruggedized casing with multiple support positions.
122 x 156 x 34 mm
0,9 kg
Technical Information
39
