Teldat REGESTA 1 Installation And Configuration Manual page 37

Teldat S.A.
4.4.2.8 SNMP TRAPS
The device can send some SNMP traps. The purpose of this set of traps is to provide information on certain critical
events that can arise in the GSM/GPRS network state.
The device must be permanently registered in GPRS to activate this feature.
There is a list of implemented SNMP traps in ANNEX A.
The traps are sent complying with the SNMP V.1 format.
Syntax
Description
Example
Syntax
Description
Example
Syntax
Description
Example
Syntax
Description
Example
REGESTA 1
OK
AT*ZSNMPIP="<ip>"
Indicates the Host IP address where the SNMP traps must be sent.
AT*ZSNMPIP="192.23.44.56"
OK
AT*ZSNMPPORT=<port>
Indicates the Host UDP port where the SNMP traps must be sent.
<port> can take values between 1 and 65535.
AT*ZSNMPORT=162
OK
AT*ZGROUP="<group>"
Allows you to configure the group identifier used in the trap register.
The maximum size of the group identifier must be 19 characters or less.
AT*ZGROUP="TELEGES323"
OK
AT*ZCLT=<min>,<max>
Allows you to configure the RSSI threshold values, minimum and maximum, in or-
der to send the low and normal coverage level traps.
<min> Represents the RSSI value under which a LOW coverage level trap must
be sent. This can take values between 0 and 20.
<max> Represents the RSSI value above which a NORMAL coverage level trap
must be sent. This can take values between 0 and 20.
The change of trap level is only sent once when a RSSI change is produced and
generates a transition from one of the thresholds.
AT*ZCLT=8,11
OK
4 Configuration
33
