2 Web Interface
Note
The "Save", "Reboot" and "Restore default configuration" buttons are only available if the logged-in
user has been assigned a "root" or "configuration" access level.
The data shown is as follows:
• Router Software version: Router's CIT version.
• MAC: Physical Ethernet address.
• Router Model:Regesta-PLC model and router license.
• Processor: Processor.
• Serial number: Router's serial number.
There are three buttons at the bottom of the page that execute the following actions:
• Save Button: Lets you save any changes made in the router configuration.
• Reboot Button: Lets the user reboot the router from the Web. On clicking on this button, the user is automatically
logged out and redirected to the application disconnection page.
• Restore default configuration Button: Lets you reestablish the router default configuration, which automatically re-
starts for changes to be effective. On reboot, the user is automatically redirected to the application disconnection
page.
Note
• For the changes executed in the router configuration via the Web Configurator to activate, you first
need to save the changes through the "Save" button and then reboot the router using the "Reboot"
button.
• If you reestablish the default configuration, you will lose all changes previously made to the router's
configuration.
From this home page, and depending on his/her access level, the user can enter the remaining Web Configurator
pages. The following sections describe the configuration/monitoring screens in the order in which they appear in the
bar at the top of the page.

2.3 Status menu

The Status menu allows you to access information on the various aspects of the router status.
Menu Status – REGESTA-PLC with 1 2G/3G/LTE module and PRIME technology
Fig. 14:

2.3.1 WWAN-1 Status

Summarizes the parameters that characterize the cellular interface for module 1.
6
