5. DeviceNet Connection Object (Class ID: 05h)
5-1. Class attribute
ID Access rule
- -
5-2. Class common service
Service code
-
5-3. Instance attribute1 (Explicit message)
ID Access rule
1 Get
2 Get
3 Get
4 Get
5 Get
6 Get
7 Get
8 Get
9 Get/Set
12 Get/Set
13 Get
14 Get
15 Get
16 Get
17 Get
5-4. Instance attribute2 (I/O: Poll message)
ID Access rule
1 Get
2 Get
3 Get
4 Get
5 Get
6 Get
7 Get
8 Get
9 Get/Set
12 Get/Set
13 Get
14 Get
15 Get
16 Get
17 Get
Description Value
- -
Description
-
Description
State
Instance_type
TransportClass_trigger
TM
DeviceNet _produced_connection_id
TM
DeviceNet _consumed_connection_id
TM
DeviceNet _initial_comm_characteristics
Produced_connection_size
Consumed_connection_size
Expected_packet_rate
Watchdog_timeout_action
Produced_connection_path_length
Produced_connection_path
Consumed_connection_path_length
Consumed_connection_path
Production_inhibit_time
Description
State
Instance_type
TransportClass_trigger
TM
DeviceNet _produced_connection_id
TM
DeviceNet _consumed_connection_id
TM
DeviceNet _initial_comm_characteristics
Produced_connection_size
Consumed_connection_size
Expected_packet_rate
Watchdog_timeout_action
Produced_connection_path_length
Produced_connection_path
Consumed_connection_path_length
Consumed_connection_path
Production_inhibit_time
04 h: EX260-SDN1, EX260-SDN2
02 h: EX260-SDN3, EX260-SDN4
-24-
Value
03h
00h
83h
-
-
21h
FFFFh
FFFFh
-
-
0
None
0
None
0
Value
01h
01h
82h
-
-
01h
00h
-
-
0
None
6
20h 04h 24h xxh 30h 03h
xx can be either 25 or 23
25: EX260-SDN1, EX260-SDN2
23: EX260-SDN3, EX260-SDN4
0
