Connecting Devices; Video Surveillance - AJAX Hub 2 User Manual

Please assign a name for the room, and optionally, attach (or make) a photo: it
helps to nd the needed room in the list quickly.
By pressing on the gear button go to the room settings menu. To delete the room,
move all the devices to other rooms using the device setup menu. Deleting the
room erases all its settings.

Connecting Devices

During the rst hub registration in the app, you will be prompted to add devices to
guard the room. However, you can refuse and return to this step later.
The user can add the device only when the security system is disarmed!
Pairing device with hub:
Ajax app
1. In the , open the room and select Add Device.
2. Name the device, scan its QR code (or enter it manually), select a group (if group mode is enabled).
3. Click Add — the countdown for you to add a device will begin.
4. When the app starts searching and launches countdown, switch on the device: its LED will blink once.
For detection and pairing to occur, the device should be located within the coverage area of the
wireless network of the hub (at a single protected object).
If the connection fails on the rst try, switch off the device for 5 seconds and retry.
How to con gure and connect an IP camera to the Ajax security system

Video surveillance

You can connect third-party cameras to the security system: seamless integration
with Dahua, Hikvision, and Sa re IP cameras and video recorders has been
implemented, and you can also connect third-party cameras supporting RTSP
protocol. You can connect up to 25 video surveillance devices to the system.
