HomeSiren User Manual | Ajax Systems Support
HomeSiren is a wireless home siren with the capacity up to 105 dB.
Developed only for indoor use. It can be quickly installed and set up,
is furnished with a LED (plus allows connecting an external LED),
and can operate up to 5 years from a battery.
HomeSiren operates within the Ajax security system, by connecting
via the protected
range is up to 2,000 meters if there are no obstacles.
The siren is set up via a
based smartphones. The user is notiQed of all events through push
https://support.ajax.systems/en/manuals/homesiren/?_ga=2.204664022.754703337.1648293156-504169808.1647685641
HomeSiren User Manual
Updated February 16, 2022
Jeweller
protocol to the
mobile application
hub
. The communication
for iOS and Android-
26.03.2022 13.04
Side 1 af 28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HomeSiren and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX HomeSiren

Summary of Contents for AJAX HomeSiren

  • Page 1 HomeSiren User Manual Updated February 16, 2022 HomeSiren is a wireless home siren with the capacity up to 105 dB. Developed only for indoor use. It can be quickly installed and set up, is furnished with a LED (plus allows connecting an external LED), and can operate up to 5 years from a battery.

  • Page 2: Functional Elements

    . Connection to ocBridge Plus uartBridge integration modules is not provided. The Ajax security system is self-sustaining, but the user can connect it to the central monitoring station of a private security company. Buy home siren HomeSiren Functional elements 1. Light indicator 2.

  • Page 3: Operating Principle

    Connecting the Siren to the hub The HomeSiren siren operates only with the Ajax security system. Up to 10 sirens may be connected to the Ajax hub Before starting connection: https://support.ajax.systems/en/manuals/homesiren/?_ga=2.204664022.754703337.1648293156-504169808.1647685641...
  • Page 4 Only users with administrative privileges can add the device to the hub How to connect the siren to the hub: 1. Select the Add Device option in the Ajax application. 2. Name the device, scan/write manually the QR Code (located on the body and packaging), and select the location room.
  • Page 5 Request for connection to the hub is transmitted for a short time at the time of switching on the device. If the connection to the Ajax hub failed, the siren will switch off after 6 seconds. You may repeat the connection attempt then. To retry the connection, you do not need to turn off the device.
  • Page 6 HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 default value — 36 seconds. States Siren states can be found in the Ajax app: 1. Go to the Devices tab. 2. Select HomeSiren from the list. Parameter Value Temperature of the device. Measured on the processor and changes gradually.
  • Page 7 HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 Displayed if the siren is working via a ReX range extender name radio signal range extender Battery level of the device. Two states available: ОК Battery Charge Battery discharged How battery charge is...
  • Page 8 HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 of the state of the security system More about indication If active, the siren notiQes you about the activation and deactivation the system Beep When Arming/Disarming of the guard mode by the LED and a...

  • Page 9: Setting Up The Detector

    HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 Setting Up the Detector To change the HomeSiren settings in the Ajax app: 1. Select the hub if you have several of them or if you are using the PRO app.

  • Page 10: Night Mode

    HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 When attached to all groups, the siren and its indication are related to Alarms in Group Mode alarms and events of all groups in the system Regardless of the group selected, the...
  • Page 11 HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 More about indication Opens the siren notiQcation settings. A detailed description of the settings is Beeps Settings available below Switches the device to the volume test mode Volume Test What is Volume Level Test Switching the siren to the Jeweller signal strength test mode.
  • Page 12 HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 automation scenarios, and the system will ignore device alarms and Temporary Deactivation other notiQcations Lid only — the system will ignore only notiQcations about the triggering of the device tamper button...
  • Page 13 HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 If this option is enabled, the siren beeps to signal about an exit delay What is Delay When Exit Delays Entering/Leaving If this option is enabled, the siren beeps to signal about an entry delay in the...
  • Page 14 Setting up the processing of detector alarms Through the Ajax app, you can conQgure which detector alarms can activate the siren. This can help to avoid situations when the security system notiQes of LeaksProtect detector alarm or any other device alarm.
  • Page 15 Setting the response to pressing the panic button in the Ajax app The siren can respond to pressing the panic button in Ajax apps. Note that the panic button can be pressed even if the system is disarmed! For the siren to respond to pressing the panic button: 1.
  • Page 16 HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 Setting the siren after-alarm indication The siren can inform about triggerings in the armed system by means of LED indication. The option functions as follows: 1. The system registers the alarm.
  • Page 17 3. Select the sirens needed. Go back to Siren Settings. The set parameters will be saved. 4. Click Back. All values will be applied. HomeSiren with Qrmware 5.55.2 and later supports this function. How to set Chime Chime is a sound signal that indicates the triggering of the opening detectors when the system is disarmed.
  • Page 18 HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 setting up opening detectors. Learn more about Chime HomeSiren with Qrmware 5.55.1.0 and later supports this function. Siren settings 1. Go to the Devices menu. 2. Select the siren. 3. Go to its settings by clicking the gear icon in the upper right corner.
  • Page 19 HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 7. Click Back to save the settings. 8. Repeat steps 2–7 for other sirens on which you want to enable the notiQcations. Detectors settings 1. Go to the Devices menu. 2. Select the detector.

  • Page 20: Performance Testing

    Battery low (if the indication is activated), the tamper is actuated or alarm is given Performance testing The Ajax security system allows conducting tests for checking the functionality of connected devices. https://support.ajax.systems/en/manuals/homesiren/?_ga=2.204664022.754703337.1648293156-504169808.1647685641 Side 20 af 28...

  • Page 21: Installing The Siren

    Jeweller Signal Strength Test Attenuation Test Installing the Siren Location of the HomeSiren determines its remoteness from the hub and presence of any obstacles between the devices, hindering the radio signal and sound transmission: walls, inserted joors, large- size objects located within the room.

  • Page 22: Installation Process

    HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 If the signal level is one division, we cannot guarantee stable operation of the security system. Take possible measures to improve the quality of the signal! As a minimum, move the device —...

  • Page 23: External Led Connection

    LED. If the light indicator of the siren is not actuated after installation in SmartBracket, check the tamper mode in the Ajax Security System application and then the Qxing tightness of the device on the panel.
  • Page 24 Outlet power supply: 3 V, 10 mA. Siren Maintenance and Battery Replacement Check the operational capability of the HomeSiren on a regular basis. Clean the siren body from dust, spider web and other contaminations as they appear. Use soft dry napkin suitable for equipment maintenance.

  • Page 25: Battery Replacement

    HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 Battery Replacement Tech specs Type of notiQcation Acoustic and LED 81 – 105 dB at a distance of 1 m Sound notiQcation volume (adjustable) Operating frequency of the buzzer 3.4 ± 0.5 kHz...

  • Page 26: Compliance With Standards

    HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 Battery supply 2 × CR123A, 3 V Battery life Up to 5 years Socket for connecting Yes (power supply 3 V, 10 mA) an external light indicator Body protection level IP50...

  • Page 27: Warranty

    HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 2. SmartBracket mounting panel 3. Battery CR123A (pre-installed) — 2 pcs 4. LED connection clamp 5. Installation Kit 6. Quick Start Guide Warranty Warranty for the “AJAX SYSTEMS MANUFACTURING” LIMITED LIABILITY COMPANY products is valid for 2 years after the purchase and does not apply to the pre-installed battery.
  • Page 28 HomeSiren User Manual | Ajax Systems Support 26.03.2022 13.04 Subscribe to the newsletter about safe life. No spam Email Subscribe https://support.ajax.systems/en/manuals/homesiren/?_ga=2.204664022.754703337.1648293156-504169808.1647685641 Side 28 af 28...
