2.3. Electrical and Mechanical Specifications

The TIM meets all applicable environmental, EMI, and vibration tolerance specifications
for Class C equipment. Table 2-1 and Table 2-2 list the TIM specifications.
PARAMETER
System Power Source Voltages
Temperature Range
Humidity
Vibration
EMI
Isolation and Protection
Height
Width
Depth, including connectors
Recommended clearance depth
(including cables)
Weight
Mounting

2.4. Operating Overview

The MLK continuously monitors various operational parameters and maintains an
internal log of important system event, warning, and error conditions. The TIM looks for
the occurrence of pre-configured SNMP Trap/Inform events within this log. If a
configured Trap/Inform event is detected, the TIM captures data from the controller log
and triggers a message to a host system database. Notifications of the Trap/Inform
event may be delivered by the host to pre-configured recipients by e-mail, fax, text
message, or accessed through direct access to the host system.
The TIM contains an embedded web server. This server allows users to access alarm
and status data, remotely reset the MLK, and perform basic setup of the TIM on the
network using a web browser interface. Optionally, the device may be connected to any
wired IP network for communication with a host system.
Copyright 2019
Table 2-1. Operating Specifications
Table 2-2. Mechanical Specifications
PARAMETER
SM-1H1.0002 Rev. 2, March 2019
TransPortalTM Interlock Monitor
VALUE
8 to 30VDC, 10W
–40 to +70°C
0% to 95% non-condensing per AREMA 11.15.1
Per AREMA 11.15.1
Per AREMA 11.15.1
Per AREMA 11.3.3
VALUE
2.625 inches
9.5 inches including mounting flanges
7.5 inches
9.0 inches
3 lbs.
Wall or Shelf Flange Mount, Horizontal
