Hitachi TransPortal Installation, Operation, Troubleshooting page 30

The data shown in these web page views are only
representative of the configuration data required for a
specific interlocking.
interlocking-specific data for that location.
Each TIM must also be configured with specific network-
and SNMP-host interface parameters for that location.
• Open Ports Table – Allows viewing and configuring available inbound ports.
Only three ports (1, 2, and 3) are used in this TIM application.
Inbound Port – Enter the numeric address for each active incoming
connection. Valid port addresses range from 1 to 65535.
Protocol – Select the port protocol from the dropdown list (TCP or UDP).
• Enable Port Forwarding – Not used in this TIM application.
• Enable NAT – Select "Yes" for this TIM application and enter the following:
Source Network Address – Enter the numeric IP address for the source to
be translated. Each field should be a whole number between 1 and 255.
Source Interface – Enter the name of the network interface (typically "eth0")
containing the source network address to be translated.
Destination Interface – Enter the name of the network interface (typically
"ppp0") that is to receive the translation output.
• Time Synchronization – Select the desired synchronization method and time
server(s).
Time Synchronization – Only the NTP method for synchronizing time is
available in this TIM application.
NTP Servers to Use – Enter the IP address or FQDN of the server(s) the TIM
should synchronize with.
Copyright 2019
NOTE
Each TIM must be configured with
SM-1H1.0002 Rev. 2, March 2019
TransPortalTM Interlock Monitor
4-8
