WALK TEST

3-1 WALK TEST
Set DIP switch 1 (LED) to "ON".
1
DIP switch
ON
1
ON
1 2 3 4
Note>>
• The switch is set to "ON" by factory default.
If the LED does not need to be turned on at all times,
3
set the DIP switch 1 (LED) to "OFF".
DIP switch
ON
1
ON
1 2 3 4
4

DIP SWITCH SETTING

ON
1
ON ON
1 1 2 2 3 3 4 4
●: Factory default
4-1

LED

ON
ON
1 2 3 4 OFF
4-2

ALARM OUTPUT

N.O.
ON
N.C.
1 2 3 4
4-3

PIR SENSITIVITY

STD
ON
1 2 3 4 LOW
2 3 4
2 3 4
DIP switch
1 LED
2 ALARM OUTPUT
3 PIR SENSITIVITY
2 3 4
4 ANTI-MASKING
Position
ON
(Factory default)
OFF
Position
N.O.
N.C.
(Factory default)
Position
STD
(Factory default)
LOW
Check that LED lights for 2 seconds
2
when the intended object is detected.
Detected
EN-5
Not detected
Do not touch the PCB except
for the DIP switch and the
terminal.
DIP switch 1
Function
LED ON
LED OFF
DIP switch 2
Function
N.O. output
N.C. output
DIP switch 3
Function
Normal sensitivity
Low sensitivity
FTN-ST
FTN-AM
FTN-ST
FTN-AM
FTN-ST
FTN-AM
