WIRELESS OUTDOOR
WIRELESS OUTDOOR
DETECTOR
DETECTOR
FTN-RRHW/FTN-RRIX
FTN-RRHW/FTN-RRIX
FTN-RR2G/FTN-RRDS
FTN-RR2G/FTN-RRDS
FTN-RRHW Honeywell 5800 Series Compatible
FTN-RRIX
Interlogix 319.5MHz Compatible
Product is not produced by, endorsed by, nor is officially associated with Honeywell, Interlogix, 2GIG or DSC.
FEATURES
• Narrow Angle Detection
• Detection Range Adjustability (2m / 5m)
• Intelligent 'AND' logic
• Horizontal Adjustability
• Tamper Output
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference that may be received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the
Resolution Products, Inc. could void the user's authority to operate
this equipment.
IC NOTICE
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux cnr d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes:
(1) L'appareil ne doit pas produire de brouillage, et
(2) L'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
"Honeywell", "2GIG", "Interlogix", "DSC" are trademarks owned by
Honeywell International, Inc, Nortek Security & Control LLC, United
Technologies Corporation, and Tyco Safety Products Canada LTD,
respectively.
OPTEX Inc. products will function with one of either Honeywell,
2GIG, Interlogix, or DSC systems. However, no OPTEX Inc.
product is produced by, endorsed by, nor is officially associated
with Honeywell, 2GIG, Interlogix, DSC.
OPTEX Inc. recommends verifying proper enrollment and
operation, per control panel installation instructions, at installation.
INSTALLATION INSTRUCTIONS
FTN-RR2G 2GIG Compatible
FTN-RRDS DSC 433MHz Compatible
CONTENTS
1-1 BEFORE INSTALLATION .................. 2
1-2 ZONE CONFIGURATION .................. 3
1-3 PARTS IDENTIFICATION.................. 3
1-4 DETECTION AREA ............................ 4
2-1 WIRING DIAGRAM ............................ 4
2-2 ENROLLING TO PANEL.................... 5
2-3 MOUNTING........................................ 9
3-1 WALK TEST ..................................... 12
4-1 WALK TEST MODE ......................... 12
4-2 BATTERY SAVING TIMER .............. 13
4-3 ALARM & TROUBLE OUTPUT........ 13
4-4 LED .................................................. 13
4-5 PIR SENSITIVITY ............................ 13
5-1 LED LIGHT PATTERN ..................... 14
6-1 HOW TO REPLACE BATTERY ....... 15
6-2 BATTERY LIFE ................................ 15
7-1 SPECIFICATIONS ........................... 16
7-2 DIMENSIONS................................... 16
- 1 -
59-2624-0
Advertisement
Table of Contents
Related Manuals for Optex FTN-RRHW
Summary of Contents for Optex FTN-RRHW
-
Page 1: Table Of Contents
Technologies Corporation, and Tyco Safety Products Canada LTD, 7 SPECIFICATIONS respectively. OPTEX Inc. products will function with one of either Honeywell, 7-1 SPECIFICATIONS ......16 2GIG, Interlogix, or DSC systems. However, no OPTEX Inc. product is produced by, endorsed by, nor is officially associated 7-2 DIMENSIONS........ -
Page 2: Introduction
INTRODUCTION BEFORE INSTALLATION Failure to follow the instructions provided with this indication and improper Warning handling may cause death or serious injury. Failure to follow the instructions provided with this indication and improper Caution handling may cause injury and/or property damage. The check mark indicates recommendation. -
Page 3: Zone Configuration
Mounting base Accessories>> Screw kit Bracket Screw cap For wall mounting Screw (3 × 20 mm) Main unit cover Note>> FCC ID FTN-RRHW: U5X-RE201X Main unit FTN-RR2G: U5X-RE201X Transmitter FTN-RRIX: U5X-RE101X Lens compartment FTN-RRDS: U5X-RE301 IC ID FTN-RRHW: 8310A-RE201 FTN-RR2G: 8310A-RE201... -
Page 4: Detection Area
DETECTION AREA Top view Side view 5 m detection length Adjustable range: 95° (by 5° pitch) 2 m detection length Adjustable range: 95° (by 5° pitch) INSTALLATION WIRING DIAGRAM - Overall wiring diagram Red: Power input (+) Bracket Black Black: Power input (-) Transmitter White White: Alarm... -
Page 5: Enrolling To Panel
ENROLLING TO CONTROL PANEL Enrolling to Honeywell LYNX Touch L5210/L7000 Series 1. Place the panel into wireless enrollment mode and then trip the tamper three times. 2. Set “Loop Number” to 1. 3. Set “Device type” to “Other”. 4. Set “Response Type” and “Alarm Report” according to following table. 5. - Page 6 ENROLLING TO CONTROL PANEL Enrolling to 2GIG GC2/GC3 1. Select “RF Sensor #” (01 to 48). 2. Select “Sensor Type” according the following table. 3. Select “Sensor Equipment Code” as “[0000] Other or [0609] Existing Motion Detector”. 4. Select “Sensor Other Equip code as “[0]” (this menu only appears if [0000] Other was selected in the previous menu.
- Page 7 ENROLLING TO CONTROL PANEL Enrolling to DSC PowerSeries 1. Put control panel into learn sensor mode. 2. Push tamper switch to enroll FITLINK. 3. Press [*] key to confirm ID. 4. Enter [zone #]. 5. Enter [zone type] according to the following table. 6.
- Page 8 ENROLLING TO CONTROL PANEL Enrolling to Interlogix Simon XTi 1. Put control panel in learn sensor mode. 2. Push tamper switch to enroll FITLINK. 3. Enter “Sensor Number” 4. Select “Sensor group” according to following table. 5. Change “Sensor Name” of Item 1 to the correct name from the list. 6.
-
Page 9: Mounting
MOUNTING Remove the mounting base. Open the knockout. Mounting base Joint screw knockout Joint screw knockout Mount the mounting base on the wall. Screw (3 × 20 mm) 100 mm Use this knockout screw hole to mount the base, when making the wall tamper switch effective. - Page 10 Determine the horizontal detection angle and attach the fixture. Notes>> Note>> • Align the detection area parallel to • To make adjustments, remove the fixture. the wall to reduce interference with the wall. Note>> • Check that the fixture and •...
- Page 11 Determine the detection length. (2 m or 5 m) If 2 m is required, rotate the lower lens 180 degrees. Note>> • Do not remove the upper lens. 5 m detection length 2 m detection length (Factory default) Side view Side view Attach the fixture.
-
Page 12: Walk Test
WALK TEST WALK TEST Set the DIP switch 1 (WALK TEST Check that LED lights for 2 seconds MODE) to “ON (TEST)”. when the intended object is detected. DIP switch Detected Not detected Note>> • The switch is set to “ON (TEST)” by factory default. -
Page 13: Battery Saving Timer
BATTERY SAVING TIMER DIP switch 2 Position Function 5 sec. 120S Note>> 120S • The detector will not generate 120 sec. (Factory alarms at intervals shorter default) than the specified time. ALARM & TROUBLE OUTPUT DIP switch 3 Position Function N.O. -
Page 14: Others
OTHERS LED LIGHT PATTERN The following explains the LED light pattern. Blink Light Warm-up Note>> • The LED blinks even if the DIP switch 4 (LED) is set to “OFF”. Blinks for approx. 120 seconds. Alarm Lights for 2 seconds. - 14 -... -
Page 15: Battery
BATTERY The detector shares the battery with the transmitter. HOW TO REPLACE BATTERY Replace the battery. Remove the bracket and main section. Install a new battery. Attach the bracket and main section. BATTERY LIFE The values indicated are only for reference on each condition. CR123A (3 V, 1300 mAh) Alarm trigger per day Battery Life... -
Page 16: Specifications
OPTEX SECURITY Sp.z o.o. (Poland) OPTEX (DONGGUAN) CO.,LTD. SHANGHAI OFFICE (China) URL: http://www.optex.net/br/es/sec URL: http://www.optex.com.pl URL: http://www.optexchina.com OPTEX (EUROPE) LTD. / EMEA HQ (U.K.) OPTEX PINNACLE INDIA, PVT., LTD. (India) URL: http://www.optex-europe.com URL: http://www.optex.net/in/en/sec OPTEX (Thailand) CO., LTD. (Thailand) URL: http://www.optex.net/th/th OPTEX TECHNOLOGIES B.V.
