INSTALLATION

2-1 INSTALLATION
Open the main unit cover.
1
Put the wire extending from the wall through the
4
wiring hole in the bottom of the bracket, and
mount the bracket on the wall.
Screw (3 × 20 mm)
83.5 mm
(3.29 inches)
Screw (3 × 20 mm)
Note>>
• For wall tamper wiring (option), refer to 5-1.
Sponge
Wire terminal connections.
6
FTN-ST
+ -
AL C SP TP TP
-Power cable length
The power cable should be limited to the following length.
Cable diameter
AWG22 (0.33 mm )
2
AWG20 (0.52 mm )
2
AWG18 (0.83 mm )
2
Remove the fixture.
2
Fixture
Mounting height:
0.8 to 1.2 m
(2.6 to 3.9 ft.)
FTN-AM
+ -
AL C TR TP TP
FTN-ST
12 V
340 (1120) 730 (2400)
530 (1740) 1160 (3810)
850 (2790) 1850 (6070)
EN-3
Hold the top of the bracket
3
lifted and remove the main unit.
Pull the wire through the main unit.
5
Lift the top of the bracket slightly and mount the main
unit to the bracket.
2.
1.
Notes>>
• Anti-masking output is recognized as
TROUBLE.
• For EOL, refer to 5-2.
14 V 12 V
290 (950)
450 (1480)
720 (2360)
Bracket
Main unit
1.
2.
3.
Unit: m (ft.)
FTN-AM
14 V
620 (2030)
980 (3220)
1570 (5150)
